Features:
Die-cast aluminum Planer table, stronger than normal used steel plate
160mm max clearance height forthicknesser
Cast Iron Thicknesser table, stronger than steel or die-case aluminum table with higher precision
Precise thickness adjustment forquick and exact planing
Planer blades with double bladefor longer service life
No-voltage release switch prevents unintentional start up after power off
Powerful induction motor brings stronger lugging drive and even planing performance
Specifications | |
Power input | 2200w Induction motor |
Max cutting width | 260mm |
Max cutting Thickness | 3/3mm |
Planer cutting depth | 7- 160mm |
Feed speed | 5m/min |
Qty of Blade | 2 |
Speed | 6500rpm |
Fence | 650x121.4mm |
Fence angle | 90-135degree |
Dust chute diameter | 98.7mm |
Jointer Working table | 1035*285mm |
Thicknesser table size | 400*260mm |
Packing size | 710*565*570mm |
Installed working size | 1095*650*985mm |
Weight | 76/71kgs |
Loading quantity | 108/256pcs |
MOQ | 256Sets/40HQ |
